Chapter 1
Introduction to Powerline Networking
2
Powerline AV Network Adapter
A Powerline Network in a Two-Story House
This diagram shows a basic powerline network in a two-
story house. The router upstairs is connected to its Adapter,
which is plugged into an electrical outlet. Downstairs, the
gaming console and a computer share their Powerline
AV 4-Port Network Adapter, which is plugged into an
electrical outlet.
Using the powerlines of the home, the router expands
your local network to include the gaming console and
desktop computer in the living room. Internet access and
files can be shared between your computers and other
networked devices.
For online gaming, you can play downstairs in the comfort
of your living room, while taking advantage of your router
and high-speed Internet connection upstairs.
Modem
Router
Computer
Gaming
Console
Powerline AV
Network Adapter
Powerline AV
4-Port Network
Adapter
Diagram of a Powerline Network in a Two-Story House
