Cisco RE1000 User Manual

4
Contents
Linksys Wireless-N Range Extender
7. Move the extender to its primary location, then click Next. Your router
tests the wireless connection to your relocated extender and prompts
you if it needs further adjustment.
TIP
You can also connect the range extender by using Wi-Fi Protected
Setup. For more information, see “Using Wi-Fi Protected Setup” on
page 7.
How to change the power plug configuration
You can connect the extender’s built-in power plug directly to a wall power
outlet. For a desktop or table-top setup, you can also remove the built-in plug
and use an AC cable instead.
To attach the AC power plug:
1. Press the plug release latch, then slide the AC plug off the extender.
2. Slide the clip cover into the slot that held the AC plug, then connect the
AC cable to the power connector.
Power connector
(European version of extender shown)

Cisco RE1000 Specifications

General

Wireless Standard	802.11n
Wireless Speed	300 Mbps
Frequency Band	2.4 GHz
Security Features	WEP, WPA, WPA2
Ethernet Ports	1 x 10/100 Mbps
Antennas	internal
