Configuring Quality of Service
QoS Advanced Mode
Cisco Small Business 300 Series Managed Switch Administration Guide 269
18
- Set—If this option is selected, use the value entered in the New Value box
to determine the egress queue of the matching packets as follows:
If the new value (0..7) is a CoS/802.1p priority, use the priority value and
the CoS/802.1p to Queue Table to determine the egress queue of all the
matching packets.
If the new value (0..63) is a DSCP, use the new DSCP and the DSCP to
Queue Table to determine the egress queue of the matching IP packets.
Otherwise, use the new value (1..4) as the egress queue number for all
the matching packets.
• Police Type—Available in Layer 2 Mode only. Select the policer type for the
policy. The options are:
- None—No policy is used.
- Single—The policer for the policy is a single policer.
- Aggregate—The policer for the policy is an aggregate policer.
• Aggregate Policer—Available in Layer 2 Mode only. If Police Type is
Aggregate, select a previously-defined (in the Aggregate Policer Page)
aggregate policer.
If Police Type is Single, enter the following QoS parameters:
• Ingress Committed Information Rate (CIR)—Enter the CIR in Kbps. See
description in the Bandwidth Page
.
• Ingress Committed Burst Size (CBS)—Enter the CBS in bytes. See
description in the Bandwidth Page
.
• Exceed Action—Select the action assigned to incoming packets exceeding
the CIR. The options are:
- None—No action.
- Drop—Packets exceeding the defined CIR value are dropped.
- Out of Profile DSCP—IP packets exceeding the defined CIR are
forwarding with a new DSCP derived from the Out Of Profile DSCP
Mapping Table.
STEP 5 Click Apply.
