Configuring Multicast Forwarding

Defining Unregistered Multicast Settings

Cisco Small Business 300 Series Managed Switch Administration Guide 165

14

- Filtering—Enables filtering of unregistered Multicast frames to the

selected interface.

STEP 5 Click Apply. The settings are saved, and the switch is updated.
