Smart Network Application (SNA)
Right-Hand Information Panel
Cisco 350, 350X and 550X Series Managed Switches, Firmware Release 2.4, ver 0.4 487
25
NOTE The Basic Information section is not displayed when selecting clients or layer 2 clouds.
Operational
Speed
100M
10G
LAG Membership Displayed only for ports
Can be None or the LAG name.
LAG15
Member Ports Appears only for LAGs and displays a list of
the interfaces that are active members in the
LAG. Consecutive ranges of interfaces are
joined by dashes.
GE1/4, GE1/6,
XG2/4-8
VLAN
Membership
Shows the active VLANs the interface is a
member in. Dashed lines are used to join
consecutive VLANs.
1, 6, 13-19,
1054, 2012-
2100, 4094
Port Utilization %
(Tx/Rx)
Appears only for ports. 80/42
LAG Type Appears only for LAGs. Possible values are
Standard or LACP.
Switchboard
Mode
Possible values:
• Access
• Trunk
• General
• Customer
• Private – Host
• Private – Promiscuous
PoE Power
Consumption
Appears only for PoE-capable ports 8900 MW
Spanning Tree
State
Displays the interface STP-state. Blocking
Forwarding
Disabled
Parameter Name Notes Example
