VLAN Management

Cisco 350, 350X and 550X Series Managed Switches, Firmware Release 2.4, ver 0.4 225

Traffic Flow

The following describes traffic flow from hosts to servers/routers or other hosts.

Figure 1 Traffic from Hosts to Servers/Routers

Isolated 1 Isolated 2

Server

Community 1 Community 1

Promiscous Promiscous

Isolated Isolated Community Community Community

Community 1

Isolated vlan Community Vlan
