Cisco SG550X-24MPP Administration Guide

Quality of Service
QoS Statistics
Cisco 350, 350X and 550X Series Managed Switches, Firmware Release 2.4, ver 0.4 445
23
To view Queues Statistics and define what statistics to display (Counter Set):
STEP 1 Click Quality of Service > QoS Statistics > Queues Statistics.
This page displays the following fields:
• Refresh Rate—Select the time period that passes before the interface Ethernet statistics
are refreshed. The available options are:
- No Refresh—Statistics are not refreshed.
- 15 Sec—Statistics are refreshed every 15 seconds.
- 30 Sec—Statistics are refreshed every 30 seconds.
- 60 Sec—Statistics are refreshed every 60 seconds.
To view a specific unit and interface, select the unit/interface in the filter and click Go.
To view a specific interface, select the interface in the filter and click Go.
The Queues Statistics Table displays the following fields for each queue:
• Queue—Packets forwarded or tail dropped from this queue.
• Transmitted Packets—Number of packets that were transmitted.
• Tail Dropped Packets—Percentage of packets that were tail dropped.
• Transmitted Bytes—Number of bytes that were transmitted.
• Tail Dropped Bytes—Percentage of bytes that were tail dropped.
