Cisco SPA112 Administration Guide

Using the IVR for Administration
Cisco SPA100Series Administration Guide 132
8
• If the menu is inactive for more than one minute, the IVR times out. You will
need to re-enter the IVR menu by pressing the star key four times: ****. Your
settings take effect after you hang up the telephone or exit the IVR. The ATA
may reboot at this time.
• To enter the decimal points in an IP address, press the * (star) key.
For example, to enter the IP address 191.168.1.105, perform the following
tasks:
–Press these keys: 191*168*1*105
–Press the # (pound) key to indicate that you have finished entering the
IP address.
–Press 1 to save the IP address or press the * (star) key to cancel your
entry and return to the main menu.
IVR Actions
IVR Action Menu
Option
Choices and Instructions
Enter IVR Menu ****
Check Internet
Addressing Method
100 IVR answers with 0, the default option
(DHCP.)
Set Internet Addressing
Method
101 DHCP: 0
Static IP: 1
PPPoE: Press 2
Check Internet IP
Address (INTERNET port)
110
Set Static IP Address
(INTERNET port)
111 Enter the IP address by using
numbers on the telephone key pad.
Use the * (star) key when entering a
decimal point.
Note: This option is available only after
you choose Static IP as the Internet
Connection Type, through option 101.
Check Network Mask 120

Cisco SPA112 Specifications

General

Supported network protocols	IPv4, IPv6, ARP, DNS, SRV, DHCP, PPPoE, ICMP, TCP, UDP, RTP, RTCP, SNTP
DHCP client	Yes
VPN support	802.1p
Security algorithms	SSL/TLS
Authentication method	SIP
Modem (RJ-11) ports	2
Ethernet LAN (RJ-45) ports	1
Voice codecs	G.711, G.726, G.729
Certification	FCC, CE, ICES, A-Tick, RoHS, UL
Fax compatibility	T.38
Output current	2 A
Output voltage	5 V
AC input voltage	100-240 V
AC input frequency	50 - 60 Hz
Storage temperature (T-T)	-25 - 70 °C
Operating temperature (T-T)	0 - 45 °C
Operating relative humidity (H-H)	10 - 90 %

Weight and Dimensions

Width	101 mm
Height	28 mm
Weight	153 g
