Cisco SPA112 Administration Guide

Configuring the Voice Settings
Regional
Cisco SPA100Series Administration Guide 72
4
Distinctive Call Waiting Tone Patterns
Distinctive Ring/CWT Pattern Names
Field Description
CWT1 Cadence Cadence script for distinctive CWT 1.
Default setting: 30(.3/9.7)
CWT2 Cadence Cadence script for distinctive CWT 2.
Default setting: 30(.1/.1, .1/9.7)
CWT3 Cadence Cadence script for distinctive CWT 3.
Default setting: 30(.1/.1, .1/.1, .1/9.7)
CWT4 Cadence Cadence script for distinctive CWT 4.
Default setting: 30(.1/.1, .3/.1, .1/9.3)
CWT5 Cadence Cadence script for distinctive CWT 5.
Default setting: 1(.5/.5)
CWT6 Cadence Cadence script for distinctive CWT 6.
Default setting: 30(.3/.1,.3/.1,.1/9.1)
CWT7 Cadence Cadence script for distinctive CWT 7.
Default setting: 30(.3/.1,.3/.1,.1/9.1)
CWT8 Cadence Cadence script for distinctive CWT 8.
Default setting: 2.3(.3/2)
Field Description
Ring1 Name Name in an INVITE’s Alert-Info Header to pick distinctive
ring/CWT 1 for the inbound call.
Default setting: Bellcore-r1
Ring2 Name Name in an INVITE’s Alert-Info Header to pick distinctive
ring/CWT 2 for the inbound call.
Default setting: Bellcore-r2
Ring3 Name Name in an INVITE’s Alert-Info Header to pick distinctive
ring/CWT 3 for the inbound call.
Default setting: Bellcore-r3

Cisco SPA112 Specifications

General

Supported network protocols	IPv4, IPv6, ARP, DNS, SRV, DHCP, PPPoE, ICMP, TCP, UDP, RTP, RTCP, SNTP
DHCP client	Yes
VPN support	802.1p
Security algorithms	SSL/TLS
Authentication method	SIP
Modem (RJ-11) ports	2
Ethernet LAN (RJ-45) ports	1
Voice codecs	G.711, G.726, G.729
Certification	FCC, CE, ICES, A-Tick, RoHS, UL
Fax compatibility	T.38
Output current	2 A
Output voltage	5 V
AC input voltage	100-240 V
AC input frequency	50 - 60 Hz
Storage temperature (T-T)	-25 - 70 °C
Operating temperature (T-T)	0 - 45 °C
Operating relative humidity (H-H)	10 - 90 %

Weight and Dimensions

Width	101 mm
Height	28 mm
Weight	153 g
