25
Chapter 5: Configuring the Switch through the Web Utility
System Information
24-Port 10/100 + 2-Port Gigabit Switch with Webview and Power over Ethernet
System Information
The System Information tab includes links to the following screens.
• System Description
• System Mode
• Forwarding Database
• Time Synchronization
• CPU Performance
• Logout
System Description
The System Description screen displays the following information.
Model Name. This displays the switch’s name.
System name. Assign a name to the switch system, up to 255 characters long.
System Location. Assign a name to the system location, up to 255 characters long.
System Contact. Enter the name of the administrator responsible for the system, up to 255 characters long.
System up time. Length of time the management agent has been up.
IP Address. The IP Address assigned to the Switch is displayed. (The default IP address is 192.168.1.254.)
Base MAC Address. The MAC Address of the switch is displayed.
Hardware version. The current hardware version is displayed.
Software version. The current software version is displayed.
Click the Submit button after you have verified that the information is correct.
Figure 5-4: Sys. Info - System Information
