Cisco SX80 User Manual

Page 2 of 19
MBTelehealth - SX80 with Touchpad10 User Guide
Table of Contents
OVERVIEW .....................................................3
BASIC NAVIGATION ..............................................4
GENERAL USE ..................................................5
Setup ......................................................................5
Camera Controls .............................................................6
Microphone ..................................................................8
Volume .....................................................................9
Site to Site Calls ..............................................................9
Connecting to an MBT Site ............................................................ 9
Connecting to a site outside the MBT Network ............................................ 10
Far End Control: Site to Site .......................................................... 10
Sharing Presentation: Site to Site ...................................................... 11
Screen Layout: Presentation - Site to Site ............................................... 11
Recent Calls and Favourites ....................................................12
Multi-Site Event Calls (MCU) ....................................................13
Connecting to a Multi Site (MCU) Call ................................................... 13
Screen Layout/Far End: No Presentation - Multi-Site ....................................... 14
Sharing Presentation: Multi Site ....................................................... 14
Screen Layout: Presentation - Multi Site ................................................ 15
Receiving and Ending Video Calls ................................................16
DUAL VIDEO ENABLED EQUIPMENT ................................17
TROUBLESHOOTING .............................................18
ADDITIONAL TRAINING INFORMATION ..............................19
VIDEOCONFERENCING ETIQUETTE ................................19

Cisco SX80 Specifications

General

Audio Standards	G.711, G.722, G.722.1, G.729, AAC-LD, OPUS
Video Outputs	2 x HDMI
IP Protocol	IPv4, IPv6
Frame Rate	Up to 60 fps
USB Ports	2 x USB 2.0
Video Standards	H.264, H.265
Video Inputs	3 x HDMI, 1 x DVI-I
Audio Outputs	2 x HDMI
Network Interfaces	1 x Ethernet (RJ-45) 10/100/1000 Mbps
Maximum Resolution	3840 x 2160 (4K)
Power Supply	100-240V AC, 50/60Hz
Dimensions	440 x 290 x 44 mm
Wireless Connectivity	Not supported
Operating Temperature	0°C to 40°C
Storage Temperature	-20°C to 60°C (-4°F to 140°F)
Humidity	10% to 90% RH
Audio Inputs	1 x 3.5mm jack
