Cisco UCS B200 M3 Installation And Service Note

g) Press F10 to save and exit. Allow the server to reboot, but watch for the prompt to press F2 in the next step.
Step 3
Enable TPM State in the BIOS.
a) Press F2 during reboot to enter the BIOS setup screens.
b) On the Advanced tab, select Trusted Computing and press Enter to open the TPM Security Device Configuration
window.
c) Set the TPM State option to Enabled.
d) Press F10 to save and exit. Allow the server to reboot, but watch for the prompt to press F2 in the next step.
Step 4
Verify that TPM Support and TPM State are enabled.
a) Press F2 during reboot to enter the BIOS setup screens.
b) On the Advanced tab, select Trusted Computing and press Enter to open the TPM Security Device Configuration
window.
c) Verify that TPM Support and TPM State are set to Enabled.
d) Continue with enabling the Intel TXT feature in the next step.
Step 5
Enable the Intel TXT feature in the BIOS.
a) Choose the Advanced tab.
b) Choose Intel TXT (LT-SX) Configuration to open the Intel TXT (LT-SX) Hardware Support window.
c) Set TXT Support to Enabled.
d) Verify that the following items are listed as Enabled:
•
VT Support (default is Enabled)
•
VT-d Support (default is Enabled)
•
TPM Support
•
TPM State
If VT Support and VT-d Support are not enabled, return to the Advanced tab, select Processor Configuration, and
then set Intel (R) VT and Intel (R) VT-d to Enabled.
e) Press F10 to save and exit.
Server Troubleshooting
For general troubleshooting information, see the see the Cisco UCS Manager B-Series Troubleshooting Guide.
Server Configuration
Cisco UCS blade servers are intended to be configured and managed using Cisco UCS Manager. For details, see the Configuration
Guide for the version of Cisco UCS Manager that you are using. The configuration guides are available at the following URL: http:/
/www.cisco.com/en/US/products/ps10281/products_installation_and_configuration_guides_list.html
34

Cisco UCS B200 M3 Specifications

General

System bus rate	8 GT/s
Processor family	Intel
Processor socket	LGA 2011 (Socket R)
Intel Xeon series	E5-2600
Motherboard chipset	Intel C600
Compatible processor series	Intel® Xeon®
Number of processors supported	2
ECC	Yes
Memory form factor	240-pin DIMM
Number of DIMM slots	24
Supported memory types	DDR3-SDRAM
Maximum internal memory	768 GB
RAID levels	0, 1
Storage drive sizes supported	2.5 \
Supported storage drive interfaces	Serial Attached SCSI (SAS), Serial ATA III
USB 2.0 ports quantity	0
On-board graphics card model	Matrox G200
Chassis type	-
Product color	Silver
Storage temperature (T-T)	-40 - 65 °C
Operating temperature (T-T)	10 - 35 °C
Operating relative humidity (H-H)	5 - 93 %
Harmonized System (HS) code	84714100

Weight and Dimensions

Depth	620 mm
Width	203 mm
Height	50 mm
Weight	4360 g
