Cisco UCS B200 M3 Installation And Service Note

Powering Off Blade Servers Using the Power Button
You can also shut the server down remotely using Cisco UCS Manager. For details, see the Configuration
Guide for the version of Cisco UCS Manager that you are using. The configuration guides are available
at the following URL: http://www.cisco.com/en/US/products/ps10281/products_installation_and_
configuration_guides_list.html
Tip
Procedure
Step 1
For each server in the chassis that you want to power off, check the color of the Power Status LED.
•
Green indicates that the server is running and must be shut down before it can be safely powered off. Go to Step 2.
•
Amber indicates that the server is already in standby mode and can be safely powered off. Go to Step 3.
Step 2
Press and release the Power button, then wait until the Power Status LED changes to amber.
The operating system performs a graceful shutdown and the server goes to standby mode.
To avoid data loss or damage to your operating system, you should always invoke a graceful shutdown of the
operating system.
Caution
Step 3
(Optional) If you are shutting down all blade servers in a chassis, disconnect the power cords from the chassis to completely
power off the servers.
Step 4
Remove the appropriate servers from the chassis.
Removing a Blade Server
Using UCS Manager, decommission the server before physically removing the server. To remove a blade server from the chassis,
follow these steps:
Procedure
Step 1
Loosen the captive screw on the front of the blade.
Step 2
Remove the blade from the chassis by pulling the ejector lever on the blade until it unseats the blade server.
Step 3
Slide the blade part of the way out of the chassis, and place your other hand under the blade to support its weight.
Step 4
Once removed, place the blade on an antistatic mat or antistatic foam if you are not immediately reinstalling it into another
slot.
Step 5
If the slot is to remain empty, install a blank faceplate (N20-CBLKB1) to keep dust out of the chassis.
8

Cisco UCS B200 M3 Specifications

General

System bus rate	8 GT/s
Processor family	Intel
Processor socket	LGA 2011 (Socket R)
Intel Xeon series	E5-2600
Motherboard chipset	Intel C600
Compatible processor series	Intel® Xeon®
Number of processors supported	2
ECC	Yes
Memory form factor	240-pin DIMM
Number of DIMM slots	24
Supported memory types	DDR3-SDRAM
Maximum internal memory	768 GB
RAID levels	0, 1
Storage drive sizes supported	2.5 \
Supported storage drive interfaces	Serial Attached SCSI (SAS), Serial ATA III
USB 2.0 ports quantity	0
On-board graphics card model	Matrox G200
Chassis type	-
Product color	Silver
Storage temperature (T-T)	-40 - 65 °C
Operating temperature (T-T)	10 - 35 °C
Operating relative humidity (H-H)	5 - 93 %
Harmonized System (HS) code	84714100

Weight and Dimensions

Depth	620 mm
Width	203 mm
Height	50 mm
Weight	4360 g
