Cisco UCS C220 M3 Quick Start Guide

9
Cisco Security Manager 4.3 UCS Server Bundles Quick Start Guide
78-21007-01
IP Address and Hostname
Changing the IP Address
To change the IP address of your server, follow the procedures for IP address assignment published by
Microsoft for Windows Server 2008, as you did when first assigning an IP address.
After changing the IP address of your server, you must restart the Security Manager Daemon Manager
by executing the following commands in a command window:
net stop crmdmgtd
net start crmdmgtd
Changing the Hostname
The default hostname for the low-end hardware configuration (16 GB RAM, 4 x 500 GB HDD) is
CSM4-UCS2-50HW. The default hostname for the high-end hardware configuration (24 GB RAM, 7 x
500 GB HDD) is CSM4-UCS2-150HW.
To change the hostname of your new Bundle, take the steps listed in the following procedure.
Caution If the hostname of the machine changes, the stability of the system is not guaranteed and it
fails in some cases.
Procedure
Step 1 Change the hostname in the OS:
a. Right-click Computer and select Properties. Or, open Control Panel and select System.
b. Under “Computer name, domain, and workgroup settings,” click Change settings.
c. Click Change to change the hostname.
d. Restart the computer.
Step 2 Stop the Security Manager Daemon Manager by executing the following command in a command
window:
net stop crmdmgtd
Step 3 Execute the CiscoWorks server hostname change script by executing the following command in a
command window:
NMSROOT\bin\perl NMSROOT\bin\hostnamechange.pl
In this command, NMSROOT is the path to the Security Manager installation directory. The default
installation directory is D:\Program Files\CSCOpx.
Tip hostnamechange.pl is a utility that updates the hostname changes in Common Services-related
directories, files, database entries, and registry entries after the hostname is changed in the OS.
Step 4 Restart the computer.

Cisco UCS C220 M3 Specifications

General

Tcase	70 °C
Bus type	QPI
Stepping	M1
FSB Parity	No
Scalability	2S
Processor cache	10 MB
Processor cores	4
System bus rate	6.4 GT/s
Processor series	Intel Xeon E5-2600
Processor socket	LGA 2011 (Socket R)
Processor codename	Sandy Bridge EP
Processor frequency	2.4 GHz
Processor cache type	Smart Cache
Processor manufacturer	Intel
Processor package size	52.5 x 45.0 mm
Processor front side bus	- MHz
Processor boost frequency	2.50 GHz
Processor operating modes	64-bit
ECC supported by processor	Yes
Graphics & IMC lithography	32 nm
PCI Express configurations	x4, x8, x16
Supported instruction sets	AVX
Thermal Design Power (TDP)	80 W
Number of processors installed	2
CPU multiplier (bus/core ratio)	24
Physical Address Extension (PAE)	46 bit
Maximum number of PCI Express lanes	40
Memory types supported by processor	DDR3-SDRAM
Memory channels supported by processor	Quad
Memory clock speeds supported by processor	800, 1066 MHz
Memory bandwidth supported by processor (max)	34.1 GB/s
Maximum internal memory supported by processor	750 GB
HDD size	2.5 \
HDD interface	-
Total storage capacity	500 GB
Compatible memory cards	SD
Maximum storage capacity	- TB
Memory slots	16
Internal memory	32 GB
Memory clock speed	1866 MHz
Maximum internal memory	- GB
USB 2.0 ports quantity	USB 2.0 ports have a data transmission speed of 480 Mbps, and are backwards compatible with USB 1.1 ports. You can connect all kinds of peripheral devices to them.
Ethernet LAN (RJ-45) ports	3
Chassis type	Rack (1U)
Power supply	450 W
Safety	UL 60950-1 No. 21CFR1040, CAN/CSA-C22.2 No. 60950-1, IEC 60950-1, EN 60950-1, IEC 60950-1, AS/NZS 60950-1, GB4943 2001
Certification	47CFR Part 15 (CFR 47), AS/NZS CISPR22, CISPR2 2, EN55022, ICES003, VCCI, EN61000-3-2, EN61000-3-3, KN22, CNS13438, EN55024, CISPR24, EN300386, KN24
Operating altitude	0 - 3000 m
Non-operating altitude	0 - 12000 m
Storage temperature (T-T)	-40 - 70 °C
Operating temperature (T-T)	0 - 40 °C
Storage relative humidity (H-H)	5 - 93 %
Operating relative humidity (H-H)	10 - 90 %
PCI Express slots version	3.0
Processor ARK ID	64588
Intel Secure Key Technology version	1.00
Intel Identity Protection Technology version	0.00
Harmonized System (HS) code	84714100

Weight and Dimensions

Depth	724 mm
Width	430 mm
Height	43.2 mm
