Cisco UCS C220 M3 Quick Start Guide

10
Cisco Security Manager 4.3 UCS Server Bundles Quick Start Guide
78-21007-01
Recovery Media and Recovery Procedure
Note In this step, you must restart the computer. Restarting the Security Manager Daemon Manager
is not sufficient.
Recovery Media and Recovery Procedure
Caution Recovery media (2 DVDs) are provided with your new Bundle. Please take care that they are not
inadvertently discarded or lost.
Note There is no recovery partition.
Caution The purpose of the following procedure is to install Windows and Cisco Security Manager from the start;
installing Windows will delete all existing Windows files and data present in the Windows (C:\) partition
on the server. Files present in the Security Manager (D:\) partition will not be deleted. If required, back
up the files present on the server and ensure that you have the Security Manager database backup stored
on another server before proceeding.
If disk corruption or other hardware failure occurs, you can use the recovery media provided with your
new Bundle to restore the OS and Security Manager. Take the steps listed in the following procedure.
Procedure
Step 1 From a laptop or other PC, log in to CIMC on the UCS server using Internet Explorer:
https://<CIMC_IPAddress>/
Refer to the UCS documentation for setting up the CIMC IP address:
http://www.cisco.com/en/US/partner/products/ps10493/prod_installation_guides_list.html
Step 2 Launch the KVM console from the CIMC web UI.
Step 3 Insert the windows recovery media in the DVD drive of the laptop or other PC.
Step 4 Mount/Map the DVD drive as virtual media from the KVM console.
Step 5 Boot the UCS server into the EFI shell.
Step 6 From the EFI shell execute following command to start Windows installation.
fs1:\EFI\BOOT\BOOTX64.EFI
Step 7 At the end of installation, enter the Windows administrator password.
Step 8 Download and install the UCS C220 M3 windows 2K8R2 x64 drivers for chipset and network devices.
Refer to the UCS documentation for installing the Windows drivers:
http://www.cisco.com/en/US/partner/products/ps10493/products_user_guide_list.html
Step 9 Turn off the Windows firewall.

Cisco UCS C220 M3 Specifications

General

Tcase	70 °C
Bus type	QPI
Stepping	M1
FSB Parity	No
Scalability	2S
Processor cache	10 MB
Processor cores	4
System bus rate	6.4 GT/s
Processor series	Intel Xeon E5-2600
Processor socket	LGA 2011 (Socket R)
Processor codename	Sandy Bridge EP
Processor frequency	2.4 GHz
Processor cache type	Smart Cache
Processor manufacturer	Intel
Processor package size	52.5 x 45.0 mm
Processor front side bus	- MHz
Processor boost frequency	2.50 GHz
Processor operating modes	64-bit
ECC supported by processor	Yes
Graphics & IMC lithography	32 nm
PCI Express configurations	x4, x8, x16
Supported instruction sets	AVX
Thermal Design Power (TDP)	80 W
Number of processors installed	2
CPU multiplier (bus/core ratio)	24
Physical Address Extension (PAE)	46 bit
Maximum number of PCI Express lanes	40
Memory types supported by processor	DDR3-SDRAM
Memory channels supported by processor	Quad
Memory clock speeds supported by processor	800, 1066 MHz
Memory bandwidth supported by processor (max)	34.1 GB/s
Maximum internal memory supported by processor	750 GB
HDD size	2.5 \
HDD interface	-
Total storage capacity	500 GB
Compatible memory cards	SD
Maximum storage capacity	- TB
Memory slots	16
Internal memory	32 GB
Memory clock speed	1866 MHz
Maximum internal memory	- GB
USB 2.0 ports quantity	USB 2.0 ports have a data transmission speed of 480 Mbps, and are backwards compatible with USB 1.1 ports. You can connect all kinds of peripheral devices to them.
Ethernet LAN (RJ-45) ports	3
Chassis type	Rack (1U)
Power supply	450 W
Safety	UL 60950-1 No. 21CFR1040, CAN/CSA-C22.2 No. 60950-1, IEC 60950-1, EN 60950-1, IEC 60950-1, AS/NZS 60950-1, GB4943 2001
Certification	47CFR Part 15 (CFR 47), AS/NZS CISPR22, CISPR2 2, EN55022, ICES003, VCCI, EN61000-3-2, EN61000-3-3, KN22, CNS13438, EN55024, CISPR24, EN300386, KN24
Operating altitude	0 - 3000 m
Non-operating altitude	0 - 12000 m
Storage temperature (T-T)	-40 - 70 °C
Operating temperature (T-T)	0 - 40 °C
Storage relative humidity (H-H)	5 - 93 %
Operating relative humidity (H-H)	10 - 90 %
PCI Express slots version	3.0
Processor ARK ID	64588
Intel Secure Key Technology version	1.00
Intel Identity Protection Technology version	0.00
Harmonized System (HS) code	84714100

Weight and Dimensions

Depth	724 mm
Width	430 mm
Height	43.2 mm
