Cisco UCS Cisco UCS C220 M3 High-Density Rack Server (Small Form Factor Disk Drive Model)
CONFIGURING the SERVER
29
STEP 8 ORDER POWER SUPPLY
The C220 M3 SFF server accommodates two power supplies. A lightly loaded server can operate
from one 650 W power supply. A fully loaded server might need to be powered with two 450 W or
two 650 W power supplies (see
Table 12). Use the power calculator at the following link to
determine the needed power based on the options chosen (CPUs, drives, memory, and so on):
https://express.salire.com/Go/Cisco/Cisco-UCS-Power-Calculator.aspx
Table 12 Power Supply PIDs
Product ID (PID) PID Description
UCSC-PSU-450W 450 W power supply
UCSC-PSU-650W 650 W power supply
NOTE: In a two power supply server, both power supplies must be identical.
