Cisco UCS Cisco UCS C220 M3 High-Density Rack Server (Small Form Factor Disk Drive Model)
52
SUPPLEMENTAL MATERIAL
192 GB
4x16 GB 2x16 GB 4x16 GB 2x16 GB 1600 12
4x16 GB 4x8 GB 4x16 GB 4x8 GB 1600 16
2x32 GB 1x32 GB 2x32 GB 1x32 GB 1600 6
256 GB
4x16 GB 4x16 GB 4x16 GB 4x16 GB 1600 16
2x32 GB 2x32 GB 2x32 GB 2x32 GB 1600 8
512 GB
4x32 GB 4x32 GB 4x32 GB 4x32 GB 1600 16
Notes . . .
1. Rows marked in yellow indicate best performance
Table 27 Recommended Memory Configurations (continued)
Total
System
Memory
Size
CPU 1 DIMMs CPU 2 DIMMs
DIMM Max
Operating
Speed
(MHz)
Total
DIMMs in
the
System
1
Blue Slots
Bank 1
(A1, B1,
C1, D1)
Black Slots
Bank 2
(A2, B2,
C2, D2)
Blue Slots
Bank 1
(E1, F1,
G1, H1)
Black Slots
Bank 2
(E2, F2,
G2, H2)
