Cisco UCS C220 M4

3-27
Cisco UCS C220 M4 Server Installation and Service Guide
OL-32473-01
Chapter 3 Maintaining the Server
Installing or Replacing Server Components
Figure 3-14 Motherboard RTC Battery Location
1 RTC battery holder on motherboard 2 Prying point on battery in holder
353096
FAN 6
FAN 5
FAN 4
FAN 3
FAN 2
FAN 1
CPU 2
CPU 1
PSU 2
PSU 1
PCIe Riser 1
PCIe Riser 2
SD 1
SD 2
2
1
