Cisco UCS C220 M4 Maintaining The Server

3-54
Cisco UCS C220 M4 Server Installation and Service Guide
OL-32473-01
Chapter 3 Maintaining the Server
Installing or Replacing Server Components
Special Considerations for Cisco UCS Fusion ioDrive3 Storage Accelerator Cards
Table 3-9 describes the requirements for the supported Cisco UCS Fusion ioDrive3 cards.
Enabling Higher Power-Draw for Fusion ioDrive3 Cards
Some Fusion ioDrive3 accelerator cards such as the 5800 GB card draw 25 W by default but can achieve
higher performance when the PCIe slot is configured to provide more than 25 W for the device.
PCIe slots that can be configured to support more than 25 W power draw: All.
All slots can support the higher device power draw of 55 W (75 W maximum) when configured with the
override parameter in the IO Accelerator VSL software.
Note See the Cisco UCS power calculator to determine the total power draw for your exact server
configuration:
http://www.cisco.com/assets/cdc_content_elements/flash/dataCenter/cisco_ucs_power_calculator/
The override parameter in the IO Accelerator VSL software (in the
/usr/modprove.d/iomemory-vsl.conf file) overrides the setting that prevents devices from drawing
more than 25 W from the PCIe slot. The parameter is enabled by device, by using the device serial
numbers.
Note The override parameter is a setting for the IO Accelerator VSL software by server and is not stored in
the device. When moved to a new server, the device defaults to the 25 W power limit until an external
power cable is added or the override parameter is enabled for that device in the new server.
Step 1 Determine the serial number of the installed Fusion device by using the fio-status command in the IO
Accelerator VSL software. Sample output is shown here:
fio-status
Adapter: Dual Controller Adapter
Table 3-9 Cisco UCS C220 M4 Requirements for Fusion ioDrive3 Cards
Card
Maximum
Number of Cards
Supported
Slots That
Support These
Cards
Slots That
Support >25W
Power
Override
Minimum
Cisco IMC
Firmware
Card Height
(rear-panel
tab)
Cisco UCS 5800 GB MLC Fusion ioDrive3
UCSC-F-FIO-5800M=
1PCIE 1All
1
1. All slots can be enabled to provide more than the default 25 W power draw for higher performance on some cards. See Enabling Higher Power-Draw for
Fusion ioDrive3 Cards, page 3-54.
2.0(2) Full height
Cisco UCS 2900 GB MLC Fusion ioDrive3
UCSC-F-FIO-2900M=
2PCIE 1
PCIE 2
Not
applicable
2.0(2) Half height
2
2. A rear-panel tab adapter is required to fit the half-height cards in full-height slots.
Cisco UCS 1450 GB MLC Fusion ioDrive3
UCSC-F-FIO-1450M=
2PCIE 1
PCIE 2
Not
applicable
2.0(2) Half height
Cisco UCS 1150 GB MLC Fusion ioDrive3
UCSC-F-FIO-1150M=
2PCIE 1
PCIE 2
Not
applicable
2.0(2) Half height

Cisco UCS C220 M4 Specifications

General

Tcase	78.9 °C
Bus type	QPI
Stepping	M1
FSB Parity	No
Scalability	2S
Processor code	SR1YA
Processor cache	25 MB
Processor cores	10
System bus rate	9.6 GT/s
Processor series	Intel Xeon E5-2600 v3
Processor socket	LGA 2011-v3
Processor threads	20
Processor codename	Haswell
Motherboard chipset	Intel C610
Processor frequency	2.3 GHz
Processor cache type	Smart Cache
Processor lithography	22 nm
Processor manufacturer	Intel
Processor package size	52.5 x 45 mm
Processor front side bus	- MHz
Processor boost frequency	3 GHz
Processor operating modes	64-bit
ECC supported by processor	Yes
PCI Express configurations	x4, x8, x16
Supported instruction sets	AVX 2.0
Thermal Design Power (TDP)	105 W
Compatible processor series	Intel® Xeon®
Supported processor sockets	LGA 2011-v3 (Socket R)
Number of processors installed	2
Physical Address Extension (PAE)	46 bit
Maximum number of PCI Express lanes	40
Memory types supported by processor	DDR4-SDRAM
Memory channels supported by processor	Quad
Memory clock speeds supported by processor	1600, 1866, 2133 MHz
Memory bandwidth supported by processor (max)	68 GB/s
Maximum internal memory supported by processor	768 GB
HDD size	- \
RAID levels	0, 1, 5, 6, 10, 50, 60, JBOD
HDD interface	-
Total storage capacity	0 GB
Maximum storage capacity	- TB
Number of HDDs installed	0
Memory slots	24
Internal memory	16 GB
Memory clock speed	2133 MHz
Maximum internal memory	384 GB
Maximum graphics card memory	8 MB
Graphics card	G200e
Graphics card family	Matrox
Intel® Virtualization Technology (Intel® VT)	VT-d, VT-x
Cabling technology	10/100/1000Base-T(X)
Ethernet interface type	Gigabit Ethernet
USB 2.0 ports quantity	USB 2.0 ports have a data transmission speed of 480 Mbps, and are backwards compatible with USB 1.1 ports. You can connect all kinds of peripheral devices to them.
Ethernet LAN (RJ-45) ports	4
PCI Express slots version	3.0
Processor ARK ID	81705
Intel Secure Key Technology version	1.00
Intel Identity Protection Technology version	0.00
Power supply	770 W
Power supply input frequency	50 - 60 Hz
Chassis type	Rack (1U)
Trusted Platform Module (TPM) version	1.2
Compatible operating systems	Microsoft Windows Server 2012 R2 Microsoft Windows Server 2012 Microsoft Windows Server 2008 R2 Red Hat Enterprise Linux Novell SUSE Linux Enterprise Server Oracle Linux (Unbreakable Enterprise Kernel (UEK)) Oracle Solaris Ubuntu Server CentOS

Weight and Dimensions

Depth	756 mm
Width	430 mm
Height	43.2 mm
