Cisco UCS E Series Troubleshooting Guide

SUMMARY STEPS
1.
In the Navigation pane, click the Server tab.
2.
On the Server tab, click RAID. The Storage Card page appears.
3.
Click the Controller Info tab.
4.
In the Settings area, the current boot drive information is displayed in the Current Boot Drive field.
DETAILED STEPS
Step 1
In the Navigation pane, click the Server tab.
Step 2
On the Server tab, click RAID. The Storage Card page appears.
Step 3
Click the Controller Info tab.
Step 4
In the Settings area, the current boot drive information is displayed in the Current Boot Drive field.
Mouse and Keyboard Use in LSI WebBIOS Flaky
This is a known problem. To work around this problem, connect a physical mouse and keyboard.
When to Use LSI WebBIOS
This section is applicable to E-Series Servers and the SM E-Series NCE. This section is not applicable to
the EHWIC E-Series NCE.
Note
Use the LSI WebBIOS under the following conditions:
•
When the LSI warning message appears at OPROM, which requires drive configuration.
•
To configure RAID arrays with SED drives.
•
To change or remove security keys and pass phrase for SED.
•
To configure foreign SED drives.
•
To clear RAID configuration before installing a new operating system.
Show Inventory Command Output Displays Unknown xxx Error Message
This error message is applicable to E-Series Servers and the SM E-Series NCE. This error message is not
applicable to the EHWIC E-Series NCE.
Note
Symptom—When you enter the show inventory command, the server is not recognized and you get the
following error message:
Router> show inventory
Troubleshooting Guide for Cisco UCS E-Series Servers and the Cisco UCS E-Series Network Compute Engine
21
Overview
Storage Troubleshooting
