Chapter 1 Overview of the Cisco VG202, Cisco VG202XM, Cisco VG204, and Cisco VG204XM Voice Gateways
Voice Gateway Deployment
Figure 1-7 Typical Deployment of a Cisco VG202, Cisco VG202XM, Cisco VG204, or
Cisco VG204XM Voice Gateway
1 Fast Ethernet port 2 Console port
3
Fast Ethernet straight-through cable
connected to an Ethernet hub 4
RJ-45-to-DB9 console cable connected to
a PC
