Cisco XR 12000 Series Installation Guide

12
Cisco XR 12000 Series Router Ethernet Line Card Installation
OL-7861-01
Removing and Installing a Line Card
Step 2 Disconnect and remove all interface cables from the ports; note the current connections of the cables to
the ports on the line card.
Step 3 Detach the line card cable-management bracket from the line card.
Step 4 Use a screwdriver to loosen the captive screw at each end of the line card faceplate. (See Figure 4a.)
Figure 4 Line Card Removal and Installation
Caution When you remove a line card, always use the ejector levers to ensure that the line card connector pins
disconnect from the backplane in the logical sequence expected by the router. Any line card that is only
partially connected to the backplane can halt the router.
Step 5 Simultaneously pivot the ejector levers away from each other to release the line card from the backplane
connector. (See Figure 4b.)
Step 6 Grasp the ejector levers and pull the line card halfway out of the slot.
Step 7 Grasp the line card and gently pull it straight out of the slot, keeping your other hand under the line card
to guide it. (See Figure 4c.) Avoid touching the line card printed circuit board, components, or any
connector pins.
Step 8 Place the removed line card on an antistatic mat, or immediately place it in an antistatic bag if you plan
to return it to the factory.
Step 9 If the line card slot is to remain empty, install a line card blank (Product Number MAS-GSR-BLANK)
to keep dust out of the chassis and to maintain proper airflow through the line card compartment. Secure
the line card blank to the chassis by tightening its captive screws.
S
LOT-0
GIGABIT ROUTE PROCESSOR
SL
OT-1
C
OLL
LINK
TX
RX
RJ-45
M
II
R
ESE
T
AUX
CO
NSO
LE
EJE
CT
ACTIVE
0
CARRIER
RX PKT
ACTIVE
1
CARRIER
RX PKT
ACTIVE
2
CARRIER
RX PKT
ACTIVE
3
CARRIER
RX PKT
Q OC-3/STM-POS
A
C
T
I
V
E
0
C
A
R
R
I
E
R
R
X
C
E
L
L
OC-12/STM-4 ATM
OC-12/STM-4 POS
A
C
T
I
V
E
0
C
A
R
R
I
E
R
R
X
C
E
L
L
ACO/LT
ALARM 1 ALARM 2
ALARM
CSC
0
F
AIL
1
0
1
2
ENABLED
C
RITICAL
M
AJO
R
MINOR
SFC
A
C
T
I
V
E
0
C
A
R
R
I
E
R
R
X
P
K
T
A
C
T
I
V
E
1
C
A
R
R
I
E
R
R
X
P
K
T
A
C
T
I
V
E
2
C
A
R
R
I
E
R
R
X
P
K
T
A
C
T
I
V
E
3
C
A
R
R
I
E
R
R
X
P
K
T
Q OC-3/STM-POS
H10705
Loosen
captive
screws
Line card
Pivot ejector
levers away
from card to
unseat card
Grasp card carrier to
slide card out of slot
a
c
b
