Removing and Installing EPAs
Step 5 Use a Phillips screwdriver to insert and tighten the screw on the EPA, 3 to 5 in-lbs, as shown in Figure 14.
Caution Apply no more than 5 in-lbs of torque when tightening the screw.
Figure 14 Inserting and Tightening the Screw on the EPA
129875
PUSH
CORNERS
TO
INSTALL
PUSH
CORNERS
TO
INSTALL
