Page 1
OWNER'S MANUAL
75 Lb. Laundry Dryer
MODELS
GAS STEAM ELECTRIC
L36USS36G L36URD36G L36URS36S L36URS36E
L36USD36G L36URS36G L36URD36S L36URD36E
MAN2075 8/99 D0036
THIS MANUAL MUST BE GIVEN TO THE EQUIPMENT OWNER.
CISSELL MANUFACTURING COMPANY
HEADQUARTERS PHONE: (502) 587-1292
831 SOUTH FIRST ST. SALES FAX: (502) 585-3625
P.O. BOX 32270 SERVICE/PARTS FAX: (502) 681-1275
LOUISVILLE, KY 40232-2270

Table of Contents

Questions and Answers

  • T
    Traci EvansAug 20, 2025
    Why is my Cissell L36USS36G motor tripping on thermal?
    • R
      Rachel CraigAug 20, 2025
      Several factors can cause the motor in your Cissell Dryer to trip on thermal overload. Here's what to investigate: * **Voltage:** Check the voltage at the motor terminals. It should be within +10% of what's listed on the motor rating plate. If not, consult your local power company. * **Wiring:** Ensure the wiring is adequately sized for the load. Consult with your local power company if needed. * **Connections:** Check and tighten any loose electrical connections. * **Airflow:** Make sure there are adequate make-up air openings; refer to the installation sheet for recommendations. * **Lint:** Clean any lint accumulation on and around the motors.
  • R
    Ray ClarkAug 26, 2025
    How to fix a noisy or vibrating Cissell Dryer?
    • J
      Jesus ColonAug 26, 2025
      To address a noisy or vibrating Cissell Dryer, check these potential issues: * **Leveling:** Ensure the dryer is properly leveled according to the manual. * **Fan:** Inspect the fan for any damage that may have altered its balance; replace if damaged. * **Basket:** Adjust the basket clearance if it's rubbing. * **V-Belt Sheaves:** Tighten the set screws and ensure proper alignment of the sheaves. * **Belt Tension:** Adjust the belt tension. * **Foreign Objects:** Remove any screws, nails, or other foreign objects caught in the basket perforations.
  • B
    Brandon SmithAug 27, 2025
    What causes a Cissell Dryer to run, but the basket won't revolve?
    • S
      Samantha Bishop DDSAug 27, 2025
      If your Cissell Dryer's motor is running, but the basket isn't revolving, the following could be the cause: * **V-Belt:** The V-belt may be broken or loose; replace or adjust the belt tension as needed. * **Motor Pulley:** The motor pulley might be loose; tighten the set screw. * **Overloading:** The basket could be overloaded; remove some of the load.
  • L
    Lisa FullerAug 30, 2025
    What to do if my Cissell Dryer is too hot?
    • S
      Sharon TapiaAug 30, 2025
      If your Cissell Dryer is running too hot, consider these possible causes and solutions: * **Incorrect Main Burner Orifice:** Replace the orifices and check with the factory for the correct size. * **Inadequate Make-Up Air:** Ensure make-up air is 4 to 6 times the exhaust area of the dryer. * **Lint Accumulation:** Remove any accumulated lint. * **Exhaust Duct Dampers:** Make sure exhaust duct dampers are fully open, or replace them if necessary. * **High Gas Pressure:** Adjust gas pressure per the rating plate. * **Restricted Exhaust System:** Check the service section for recommended sizes. Remove obstructions or lint build-up from duct work. Never use a smaller size exhaust duct; always use a larger size. * **Defective Thermostat:** Replace the thermostat.
  • S
    Shelby BrownSep 1, 2025
    What causes main burners to burn improperly in a Cissell L36USS36G Dryer?
    • K
      Kelly Tate DDSSep 1, 2025
      Several factors can lead to improper burning of the main burners in your Cissell Dryer: * **Burner Air Shutters:** Open the burner air shutters to achieve a blue flame. * **Dirt in Burner:** Blow out any dirt present in the burner. * **Gas Pressure:** Adjust gas pressure according to the rating plate if it's too high. * **Orifice Size:** If the orifice is too large, send it to the factory for the correct size. * **Exhaust Restriction:** Clean any restrictions in the exhaust.
  • H
    Heather LinSep 4, 2025
    Why does my Cissell L36USS36G not stop at the end of the time period?
    • M
      Maria HillSep 4, 2025
      If your Cissell Dryer doesn't stop at the end of the set time, the timer is likely defective and needs to be replaced.
  • J
    jaredchambersSep 6, 2025
    Why is there low or high gas flame in my Cissell L36USS36G Dryer?
    • T
      Todd BooneSep 6, 2025
      If you're experiencing a low or high gas flame in your Cissell Dryer, the main cause is likely incorrect main burner orifices. Replace the orifices and check with the factory for the correct size.
  • C
    catherine76Sep 9, 2025
    What causes main burner to cycle on and off in Cissell L36USS36G?
    • T
      tgarciaSep 9, 2025
      If the main burner in your Cissell Dryer cycles on and off, the direct spark ignition is likely defective and should be replaced.
  • R
    Rodney SkinnerSep 12, 2025
    What causes water in the steam line of my Cissell L36USS36G?
    • E
      Erika LongSep 12, 2025
      Water in the steam line of your Cissell Dryer can be due to: * **Incorrect Steam Piping:** Check the piping against the steam installation instructions. * **Trap Malfunction:** Inspect the trap for proper size and capacity. Clean or replace if dirty or sluggish. Also, check the return line for high back pressure or another malfunctioning trap.
  • D
    Daniel ThompsonSep 14, 2025
    Why does my Cissell Dryer run, but there is no steam to coils?
    • E
      Eric HaasSep 14, 2025
      If your Cissell Dryer runs but no steam reaches the coils, consider the following: * **Valve Position:** Check all valves in the steam supply and return lines to ensure they are open. * **Steam Trap:** Remove and clean the steam trap. Replace it if defective. * **Solenoid Valve and Thermostat:** For dryers with solenoid temperature control, check the operation of the solenoid valve by advancing the thermostat. If the thermostat is defective, replace it. * **Check Valve:** Verify the check valve is installed correctly, paying attention to inlet and outlet markings. Invert if necessary. * **Strainer:** Remove the plug and blow down the strainer. If heavily clogged, remove and clean it thoroughly.

Cissell L36USS36G Specifications

General IconGeneral
BrandCissell
ModelL36USS36G
CategoryDryer
LanguageEnglish
