Cissell L44FD42G - User Manual

Questions and Answers

H
Holly RamseyAug 17, 2025
Why won't my Cissell L44FD42G Dryer motor start?
- K
  Kristina DavisAug 18, 2025
  The motor might not start due to several reasons. It could be due to no power; check the fuses on circuit breakers and ensure the main control switch is ON. Another reason might be incorrect power; verify that the voltage, phase, and frequency match the specifications on the electrical rating plate. Also, make sure the timer is set correctly by turning it clockwise to the desired time. Loose wiring connections in the electrical box on the rear of the dryer or a defective starting relay could also be culprits. Check the wire connections and the relay coils and contacts.
M
Mackenzie HoganAug 20, 2025
What to do if my Cissell Dryer runs, but there is no heat?
- P
  Patricia StokesAug 20, 2025
  If your dryer runs but doesn't produce heat, several factors could be responsible. Begin by checking for the correct control voltage (24V). Then inspect the power supply and the secondary voltage on the transformer, along with the wiring and wiring diagram. Ensure the lint door is closed. Other potential issues include a defective gas valve, gas turned off, a blown fuse, or a defective door switch. Also, check the spark igniter, air switch, and gas pressure. If the air switch is not operating, clean out the lint compartment daily and check the back draft damper and duct work for obstructions. If the vacuum within the dryer drops, this can affect the dryer's operation. If none of these resolves the issue, consider a defective relay, thermostat, or safety overload thermostat.
R
Rachel MooreAug 22, 2025
Why is my Cissell Dryer motor tripping on thermal overload?
- S
  Sarah FrenchAug 23, 2025
  Several factors can cause the motor to trip on thermal overload. Low voltage at the motor terminals could be the issue; it must be within + 10% of the voltage shown on the motor rating plate. Inadequate wiring, loose electrical connections, or inadequate air supply to the dryer can also cause this problem. Check the installation sheet for recommended make-up air openings. Lastly, ensure you're cleaning lint accumulation on and around the motors regularly.
C
Chad AndersonAug 26, 2025
Why is my Cissell L44FD42G too hot?
- R
  Ralph DavisAug 26, 2025
  Several factors can cause a dryer to overheat. The main burner orifice might be incorrect, so replace the orifices and check with the factory for the correct size. Inadequate make-up air is another potential cause; ensure it's 4 to 6 times the exhaust area of the dryer. Lint accumulation, exhaust duct dampers not fully open, or high gas pressure can also contribute to overheating. Partially restricted or inadequately sized exhaust systems can also be the reason; check the service section for recommended sizes and remove any obstructions or lint build-up from the duct work. Finally, a defective thermostat could be the cause, so consider replacing it.
J
jcarrollAug 28, 2025
What to do if the basket motor of my Cissell L44FD42G Dryer will not run?
- C
  Christina TuckerAug 28, 2025
  If the basket motor isn't running, the loading door might be open, so close it securely. The door switch may be out of adjustment; adjust the switch by removing the cover and bending the Actuator Lever to clear the Switch Button 3/8" (10mm) with the cover in place. A defective door switch or a defective basket motor contactor could also be the cause; in these cases, replace the switch or contactor, respectively.
C
cassidycannonAug 30, 2025
What to do if my Cissell Dryer runs, but the basket will not revolve and is noisy?
- S
  Sean JarvisAug 30, 2025
  If the motor runs but the basket doesn't revolve and the dryer is noisy, a broken or loose V-belt is a likely culprit; replace the V-belt or adjust the belt tension. A loose motor pulley could also be the cause; tighten the set screw. Remove some of the load if the basket is overloaded or check the manual for proper leveling procedures if it is not leveled. Other potential issues include a fan out of balance (replace damaged fans), the basket rubbing (adjust basket clearance), loose V-belt sheaves (tighten set screws and ensure proper alignment), incorrect belt tension (adjust belt tension), or foreign objects caught in the basket perforations (remove any screws, nails, etc.).
M
Margaret GibsonSep 2, 2025
Why are the main burners of my Cissell L44FD42G Dryer burning improperly?
- J
  John StephensSep 2, 2025
  Improper burning of the main burners can be due to dirt in the burner, which can be resolved by blowing it out. High gas pressure could be the issue; adjust the gas pressure per the rating plate. Alternatively, the orifice might be too large, in which case you should contact the factory for correct orifices. A restricted or blocked exhaust can also cause this problem, so clean the exhaust.
K
Kari JonesSep 4, 2025
Why does my Cissell Dryer run, but there is no steam to coils?
- C
  clarkaprilSep 4, 2025
  If your dryer runs but there's no steam to the coils, start by checking all valves in the steam supply and return lines to ensure they are open. A blocked steam trap could also be the problem; remove and clean it, and replace it if it's defective. For dryers using solenoid temperature control, the thermostat controls the operation of the solenoid valve. Also, check if the check valve is installed correctly, verifying the inlet and outlet markings. Finally, a clogged strainer can cause this issue; remove the plug and blow down the strainer, or remove and clean it thoroughly if heavily clogged.
K
kingashleySep 6, 2025
Why does the main burner cycle on and off in my Cissell Dryer?
- V
  vrodriguezSep 7, 2025
  The cycling on and off of the main burner could be due to a defective ground. Check the ground connection.
M
Mary CowanSep 9, 2025
Why is there water in the steam line of my Cissell L44FD42G?
- F
  fieldsfrancisSep 9, 2025
  Water in the steam line can result from steam piping installed incorrectly; check the piping per the steam installation instructions. Another cause could be a malfunctioning trap; check the trap for size and capacity, clean it thoroughly or replace it if it's dirty or sluggish. Also, check the return line for high back pressure, or another trap charging against the trap functioning improperly.
