Cissell L44CD42S - User Manual

Questions and Answers

A
Amanda PughAug 18, 2025
Why won't my Cissell Dryer motor start?
- J
  Jeffrey MillerAug 18, 2025
  The motor might not start due to several reasons. It could be due to no power; check the fuses on circuit breakers and ensure the main control switch is ON. Another reason might be incorrect power; verify that the voltage, phase, and frequency match the specifications on the electrical rating plate. Also, make sure the timer is set correctly by turning it clockwise to the desired time. Loose wiring connections in the electrical box on the rear of the dryer or a defective starting relay could also be culprits. Check the wire connections and the relay coils and contacts.
A
Alexa WilsonAug 20, 2025
What to do if my Cissell L44CD42S Dryer runs, but there is no heat?
- D
  Dana SchwartzAug 20, 2025
  If your dryer runs but doesn't produce heat, several factors could be responsible. Begin by checking for the correct control voltage (24V). Then inspect the power supply and the secondary voltage on the transformer, along with the wiring and wiring diagram. Ensure the lint door is closed. Other potential issues include a defective gas valve, gas turned off, a blown fuse, or a defective door switch. Also, check the spark igniter, air switch, and gas pressure. If the air switch is not operating, clean out the lint compartment daily and check the back draft damper and duct work for obstructions. If the vacuum within the dryer drops, this can affect the dryer's operation. If none of these resolves the issue, consider a defective relay, thermostat, or safety overload thermostat.
Z
zwigginsAug 23, 2025
Why is my Cissell L44CD42S Dryer motor tripping on thermal overload?
- A
  Alfred RiveraAug 23, 2025
  Several factors can cause the motor to trip on thermal overload. Low voltage at the motor terminals could be the issue; it must be within + 10% of the voltage shown on the motor rating plate. Inadequate wiring, loose electrical connections, or inadequate air supply to the dryer can also cause this problem. Check the installation sheet for recommended make-up air openings. Lastly, ensure you're cleaning lint accumulation on and around the motors regularly.
J
Jason CastilloAug 26, 2025
Why is my Cissell Dryer too hot?
- K
  Keith HowardAug 26, 2025
  Several factors can cause a dryer to overheat. The main burner orifice might be incorrect, so replace the orifices and check with the factory for the correct size. Inadequate make-up air is another potential cause; ensure it's 4 to 6 times the exhaust area of the dryer. Lint accumulation, exhaust duct dampers not fully open, or high gas pressure can also contribute to overheating. Partially restricted or inadequately sized exhaust systems can also be the reason; check the service section for recommended sizes and remove any obstructions or lint build-up from the duct work. Finally, a defective thermostat could be the cause, so consider replacing it.
M
Michael KramerAug 28, 2025
What to do if the basket motor of my Cissell L44CD42S Dryer will not run?
- C
  Cole CohenAug 28, 2025
  If the basket motor isn't running, the loading door might be open, so close it securely. The door switch may be out of adjustment; adjust the switch by removing the cover and bending the Actuator Lever to clear the Switch Button 3/8" (10mm) with the cover in place. A defective door switch or a defective basket motor contactor could also be the cause; in these cases, replace the switch or contactor, respectively.
W
William McgrathAug 30, 2025
What to do if my Cissell L44CD42S runs, but the basket will not revolve and is noisy?
- S
  stevenstoneAug 30, 2025
  If the motor runs but the basket doesn't revolve and the dryer is noisy, a broken or loose V-belt is a likely culprit; replace the V-belt or adjust the belt tension. A loose motor pulley could also be the cause; tighten the set screw. Remove some of the load if the basket is overloaded or check the manual for proper leveling procedures if it is not leveled. Other potential issues include a fan out of balance (replace damaged fans), the basket rubbing (adjust basket clearance), loose V-belt sheaves (tighten set screws and ensure proper alignment), incorrect belt tension (adjust belt tension), or foreign objects caught in the basket perforations (remove any screws, nails, etc.).
T
Troy MartinSep 2, 2025
Why are the main burners of my Cissell Dryer burning improperly?
- P
  Phillip RamirezSep 2, 2025
  Improper burning of the main burners can be due to dirt in the burner, which can be resolved by blowing it out. High gas pressure could be the issue; adjust the gas pressure per the rating plate. Alternatively, the orifice might be too large, in which case you should contact the factory for correct orifices. A restricted or blocked exhaust can also cause this problem, so clean the exhaust.
S
Sabrina WongSep 4, 2025
Why does my Cissell L44CD42S Dryer run, but there is no steam to coils?
- T
  timothybryantSep 4, 2025
  If your dryer runs but there's no steam to the coils, start by checking all valves in the steam supply and return lines to ensure they are open. A blocked steam trap could also be the problem; remove and clean it, and replace it if it's defective. For dryers using solenoid temperature control, the thermostat controls the operation of the solenoid valve. Also, check if the check valve is installed correctly, verifying the inlet and outlet markings. Finally, a clogged strainer can cause this issue; remove the plug and blow down the strainer, or remove and clean it thoroughly if heavily clogged.
D
David MartinSep 6, 2025
Why does the main burner cycle on and off in my Cissell L44CD42S?
- M
  Michelle RojasSep 6, 2025
  The cycling on and off of the main burner could be due to a defective ground. Check the ground connection.
M
melissa30Sep 9, 2025
Why is there water in the steam line of my Cissell L44CD42S?
- R
  richardmortonSep 9, 2025
  Water in the steam line can result from steam piping installed incorrectly; check the piping per the steam installation instructions. Another cause could be a malfunctioning trap; check the trap for size and capacity, clean it thoroughly or replace it if it's dirty or sluggish. Also, check the return line for high back pressure, or another trap charging against the trap functioning improperly.

Summary

Key Safety Warnings and Notices

General Safety Warnings

Important safety warnings and precautions for operating the dryer to prevent hazards.

Cissell Dryer Warranty Information

Dryer Identification Nameplate Details

Location and importance of the dryer's identification nameplate for service and parts.

Manual and Machine Symbols Guide

Dryer Unpacking and Installation

Unpacking Procedures

Steps for safely unpacking the dryer and checking for shipping damage.

General Installation Guidelines and Clearances

Recommendations for dryer placement, leveling, and required clearances.

General Dryer Dimensions Overview

Gas Dryer Dimensions and Illustrations

Energy-Saver Model Diagrams

Illustrations showing dimensions for the energy-saver gas dryer model.

Steam Heated Dryer Dimensions Overview

Electric Dryer Dimensions Overview

Comprehensive Dryer Specifications

Specifications for Specific Dryer Models

Steam Dryer Specifications

Detailed specifications for steam-heated dryer models.

Electric Dryer Specifications

Detailed specifications for electric laundry dryer models.

Electrical Connections and Grounding Instructions

Gas Piping

Gas Service Requirements

Information regarding gas supply pressure and line requirements.

Gas Piping System Diagrams

Illustrations of gas loop and supply piping systems.

Gas Pipe Sizing Chart

Chart to determine appropriate gas pipe sizes based on BTU/HR and length.

Gas Piping Installation Procedures

Steps and codes to follow for proper gas piping installation.

Steam Piping Installation Procedures

Steam Piping Installation Steps

Detailed instructions for setting up steam piping connections.

Steam Piping Best Practices

Recommendations for optimal steam piping configuration and maintenance.

Steam Piping Installation Diagram

Illustration showing the correct steam piping layout.

Multiple Manifold Exhaust Installation

Exhaust Duct Sizing for Multiple Dryers

Chart for determining exhaust duct diameter based on the number of dryers.

Exhaust Fan Control Wiring

Diagram and explanation for automatic electrical control of the exhaust fan.

Multiple Dryer Exhaust Installation Diagram

Illustration of a typical dryer installation with multiple exhaust vents.

Dryer Installation with Multiple Exhaust

Guidelines for installing dryers with a shared exhaust system.

Required Dryer Make-up Air

Separate Exhaust Installation Guide

Separate Exhaust Installation Diagram

Illustration showing a preferred separate exhaust installation setup.

Dryer Air Flow and Venting

Air Flow Importance and Requirements

Explanation of air flow's critical role in dryer operation.

Exhaust Duct Size and Length Guidelines

Recommendations for exhaust duct length, bends, and restrictions.

Make-up Air Opening Guidelines

Guidelines for providing adequate make-up air openings.

Safe Dryer Operation Procedures

Tips for Energy Saving Drying

Effect of Elevation on Dryer Ratings

How dryer performance ratings are affected by operating at high altitudes.

Two Timer Model Control Panel Diagrams

Operating Instructions: Two Timer Models

Special Reversing Feature Explanation

Explanation of the basket reversing function for specific load types.

Moisture Control Model Diagrams

Operating Instructions: Moisture Control Models

Troubleshooting Common Dryer Issues

Problem Identification and Solutions

Common causes and solutions for dryer startup, heating, drying, and ignition problems.

Comprehensive Troubleshooting Chart

Direct-Spark Ignition Operation

Direct-Spark Ignition Process Flowchart

Visual flowchart detailing the direct-spark ignition sequence.

General Dryer Maintenance Guide

Cleaning and Inspection Tasks

Routine cleaning procedures for lint traps, coils, burners, and exhaust systems.

Component Lubrication and Care

Maintenance guidance for motors, belts, and gear reducers.

System Performance Checks

Checks for make-up air, gas pressure, and dryer voltage.

Burner Air Inlet Adjustment Procedure

Basket Alignment

Basket Alignment Diagrams

Illustrations detailing the points and components for basket alignment.

Basket Alignment Procedure

Step-by-step instructions for correctly aligning the dryer basket.

Basket and Spider Assembly Shimming

Shimming Procedure for Basket Alignment

Instructions for shimming the basket and spider assembly for true running.

Air Switch Adjustment Procedure

Reversing Control Timer Operation

Dwell Time Adjustment for Reversing Timer

Procedure to adjust the dwell time for the reversing timer.

Fan and Basket Rotation Control

Large Gear Reducer Maintenance Guide

Front Exploded View Illustration

Front View Parts Identification

List of parts identified in the front exploded view illustration.

Double Motor Dryer Illustration

Double Motor Dryer Parts Identification

List of parts identified for the double motor dryer illustration.

Front Panel and Door Assembly Illustration

Thermostat Assembly Illustration

Air Switch and Thermistor Assemblies

Gas Air Switch Assembly Details

Illustration and parts list for the air switch assembly used in gas models.

Reversing Control Panel Assembly Diagram

Permanent Press Control Panel Assembly Diagram

Moisture Control Panel Assembly Diagram

TM200 Gear Reducer Parts List

Gas Bonnet Assembly Diagram

Steam Bonnet (14 FPI) Assembly Diagram

Steam Bonnet (4 Coil) Assembly Diagram

Steam Bonnet (6 Coil) Assembly Diagram

Electric Heating Unit Assembly Diagram

Electric Heating Unit Specifications Table

Cissell L44CD42S Specifications

General

Brand	Cissell
Model	L44CD42S
Category	Dryer
Type	Commercial Dryer
Heat Source	Electric
Weight	600 lbs
Drum Material	Stainless Steel
Capacity	42 lb
Heating Power	18 kW
Drum Capacity	42 lbs
Control Type	Microprocessor
Width	37 in
Height	50 inches
Voltage	208-240V
