Citizen CBM-910II - CBM-910 II Parts List 1;2

CBM-910II Parts List 2/2
R P Parts No.
ＲＰ
Remarks
950037-00 PCB Assy 910-2 R JPN/EUR 24col
(1) JPN/EUR 24col
950038-00 PCB Assy 910-2 R USA 24col
(1) ＵＳＡ 24col
950039-00 PCB Assy 910-2 R JPN/EUR 40col
(1) JPN/EUR 40col
950042-00 PCB Assy 910-2 R USA 40col
(1) USA 40col
950040-00 PCB Assy 910-2 P 24 col
(1) 24 columns
950041-00 PCB Assy 910-2 P 40col
(1) 40 columns
IC3 IC3 H130006-10 CPU M30620M８A11
IC4 IC4 H120012-00 EEPROM M24C02WMN6 1 1
IC5 IC5
H150001-10
Reset IC M51953BPF 1 1
IC2 IC2 H170007-10 Regulator M5237ML 1 1
IC1 IC1 H170008-10 Regulator TA48M05F 1 1
IC201 H160001-10 I/F IC SP232ECN 1 0
IC201,IC202 H110023-10 HCMOS SN74LV05APW 0 2
IC203 H110012-00 HCMOS 74LV74APW 0 1
TA1-TA4,TA6 TA1-TA4,TA6 H240011-10 Transistor array FDS6912A 5 5
TA5 TA5 H240012-10 Transistor array FDS8958A 1 1
TR1 TR1 H200002-10 Transistor 2SA1720 1 1
TR4,TR5,TR9 TR4,TR5,TR9 H220001-10 Transistor 2SC2712 3 3
TR2,TR3 TR2,TR3
H290002-10
Transistor RN1302 2 2
TR6,TR11 TR6,TR11
H290002-10
Transistor RN1302 2 2
TR202
H290002-10
Transistor RN1302 0 1
TR201 H280005-10 Transistor 2SK3018 0 1
TR10 TR10 H280006-10 FET 2SJ327Z 1 1
TR201 H280005-10 FET 2SK3018 0 1
XTAL1 XTAL1 H630008-10 Ceramic X'tal CSTCE10M0G52-R0 1 1
SW2
H610001-10
DIPSW KSD08S 1 0
SW2 H610003-10 DIPSW KSD04S 0 1
SW1 SW1 H650014-10 Power ＳＷ SK-22H03-G7 1 1
CN1 CN1 H500050-10 Connector MOJ-D14 1 1
CN2 CN2 H500051-10 Connector 5267-17A 1 1
CN3
H500024-10
Connector 70013-025-03 1 0
CN3 H500025-10 Connector 70013-025-04 1 0
CN3 H500027-10 Connector 57RE-40360-730B(D29) 0 1
CN4 CN4 H500008-10 Connector 5267-06A 1 1
F1 F1 H620012-10 Fuse SST2 1 1
L1 L1 H640010-00 SC coil SC-03-05GS 1 1
CN5 CN5
H500005-10
Connector 5267-03A <1> <1>
Description
Q''tyRef No.
