Chapter 1 Setup
P
ar
t Names and F
unc
tions
Fr
ont V
iew
3
2
1
1
T
op cov
er window
The amount of ribbon and media remaining can be checked through
this window
.
2
T
op cov
er
Is opened vertically to set media or ribbon.
3
Operation panel
This is used to make changes and adjustments to the print
er and its
conguration
Operation panel (p.18)
