— 26 —
4.7 Removing the Battery Pack
1. Set the printer Power switch to OFF and unplug the AC adapter
from printer.
2. Remove the battery cover by (1) pressing the battery cover as shown
in the figure, lift it upward.
3. Remove cover as shown in the illustration.
4. Remove battery pack from compartment and disconnect battery
connector from main unit.
(1)
To Next Page
