3.2 Serial Interface Board
Data can be exchanged by serial communication.
Connecting the Interface Cable
1. Turn off the power.
2. Confirm the orientation of the interface cable and connect it to the port.
3. Insert the other connector firmly into the interface port of the host computer.
CAUTION
n When disconnecting the cable, always hold the connector.
n Place the interface cable so that people do not trip on it.
Notes
Do not connect multiple interfaces at the same time.
Use a serial cable with the connection layout shown below.
