3.5 Installing the Printer
The printer can be installed horizontally or mounted vertically on the wall.
At the time of shipment, the printer is set for horizontal installation. To install
the printer on the wall, put the accessory operation panel on to the original
one. This will allow easy operation panel reading when printer is wall mounted.
CAUTION!
● No screw for wall mounting is provided. Check the structure and strength of the wall
(plaster board or stronger one) and prepare two appropriate screws (round-head wood
screws of φ3.1, 16 mm or more). And fix the printer by tightening the screws in
accordance with the specified dimensions.
Hooks for wall mounting
Horizontal position
Wall mounting
To Next Page
