H874 Instruction manual
Checking and correcting the reference position
If the time or calendar is not shown correctly even after proper reception of the time
info, check whether the reference position is correct.
• If the hands and indication do not reflect the correct reference position, the time
and calendar will not be indicated accurately even if the time info is received.
What is the reference position?
The base position of all hands and calendar to
properly indicate the various functions of this
watch.
• Moon phase indication: Full moon
• Function hand: “S” (Sunday)
• Date indication: midway between “31” and
“1”
• Hour, minute and second hands: 0 hour 00
minute 0 second
• Position of the 24-hour hand: “24”
Correct reference positions
1
Push the crown in to position
0
.
2
Press and hold the upper right button
B
for 10 seconds or more.
The hands and indication start to move to the current reference positions stored
in memory.
• Release the button as the hands start to move.
3
Check the reference positions of them referring to the illustration above.
Correct
Press and release the upper right button
B
to finish the
procedure.
Wrong
Proceed to step 4 and correct the reference position.
4
Pull the crown out to position
2
.
The moon phase indication slightly moves and reference position of the
indication becomes adjustable.
5
Press and release the upper right button
B
repeatedly to change the hand/
indication to be corrected.
• Each time you press the button, the target changes as follows:
Moon phase indication
→
function hand/date indication
→
hour, minute and 24-hour hands
→
second hand
→ (back to the top)
• The hands and indications slightly move when selected to show they become
adjustable.
6
Rotate the crown to adjust the hand/indication.
• The hour, minute and 24-hour hands move synchronously.
• Rotate the crown clockwise to adjust reference position of the function hand and
date indication.
• Date indication changes to the next as the function hand rotates 5 times.
• When you rotate the crown quickly a few times, the hand/indication will move
continuously. To stop the rapid movement, rotate the crown in either direction.
7
Repeat steps 5 and 6.
8
Push the crown in to position
0
.
9
Press and release the upper right button
B
to finish the procedure.
The watch returns to normal indication.
Resetting the watch - All Reset
When the watch does not work properly, you can reset all the settings. If the power
reserve is insufficient, charge the watch first.
Be sure to perform the following operations after All Reset.
1
Correct the reference positions.
After All Reset, the watch is in the reference position adjustment mode. Refer
to step 5 and after on page
9
.
2
Set the time zone.
See page
3
.
3
Adjust the time and calendar.
When adjusting them by receiving signals manually → page
5
When adjusting them manually → page
7
1
Pull the crown out to position
2
.
The second hand and the function hand indicate the summer time setting and
power reserve respectively.
2
Press and release the upper right button
B
for 2 seconds.
The second hand points to 0 second.
3
Press and hold buttons
A
and
B
at the same time for 4 seconds or more and
release them.
The hands and indication start moving and All Reset is executed. Wait until
movement of the hands and indication stops.
The setting values after All Reset
Time
0:00:00 AM
Month and year for the
calendar
January of the second year since a leap year (second hand
position: 7 seconds)
Date
1
Day of week
S (Sunday)
World time
Time zone 0
Summer time
“
STD AU
” at all time zone
Northern/Southern
hemisphere
Northern hemisphere
Year for moon phase
2010 (second hand position: 4)
Lunar age
15 (full moon)
Calibration value for moon
phase indication
±0
