Citrix ADC MPX
Health attributes for the MPX 5900 platform
The following table lists the health attributes for the MPX 5900 platform.
Health Attribute Recommended Range
CPU 0 core (Volts) 1.77–1.81
Main 3.3 V Supply (Volts) 3.25–3.32
Standby 3.3 V Supply (Volts) 3.27–3.32
+5.0 V Supply (Volts) 4.84–4.95
+12.0 V Supply (Volts) 11.75–12.00
Battery (Volts) 3.02–3.16
5 V Standby (Volts) 5.05–5.13
CPU Fan 0 Speed (RPM) 6900–8700
CPU Fan 1 Speed (RPM) 6500–8500
System Fan Speed (RPM) 6700–8600
System Fan 1 Speed (RPM) 6600–8500
System Fan 2 Speed (RPM) 6700–8500
CPU 0 Temperature (Celsius) 39–44
CPU 1 Temperature (Celsius) 35–45
Internal Temperature (Celsius) 31–38
Power Supply 1 Status NORMAL
Power Supply 2 Status NOT PRESENT–NORMAL
Health attributes for the MPX 8900 platform
The following table lists the health attributes for the MPX 8900 platform.
Health Attribute Recommended Range
CPU 0 core (Volts) 1.77–1.81
Main 3.3 V Supply (Volts) 3.25–3.32
Standby 3.3 V Supply (Volts) 3.25–3.32
+5.0 V Supply (Volts) 4.84–4.95
© 1999–2023 Cloud Soware Group, Inc. All rights reserved. 194
