Citrix ADC MPX
Health Attribute Recommended Range
+12.0 V Supply (Volts) 11.75–12.00
Battery (Volts) 3.02–3.13
5 V Standby (Volts) 5.05–5.16
CPU Fan 0 Speed (RPM) 6600–12600
CPU Fan 1 Speed (RPM) 6300–12200
System Fan Speed (RPM) 6700–8600
System Fan 1 Speed (RPM) 6600–8500
System Fan 2 Speed (RPM) 6700–8500
CPU 0 Temperature (Celsius) 40–57
Internal Temperature (Celsius) 30–49
Power Supply 1 Status NORMAL
Power Supply 2 Status NOT PRESENT–NORMAL
Health attributes for the MPX 15000 and MPX 26000 platforms
The following table lists the health attributes for the MPX 15000 and MPX 26000 platforms.
Health Attribute Unit Minimum value Nominal value Maximum value
CPU 0 Core
Voltage
Volt 1.47 1.82 1.835
CPU 1 Core
Voltage
Volt 1.47 1.82 1.835
3_3VCC Volt 3.12 3.30 3.48
3_3VSB Volt 3.12 3.30 3.48
5VCC Volt 4.72 5.00 5.28
p12V Volt 11.33 12.00 12.67
VBAT Volt 2.75 3.00 3.200
Vtt ‑NA‑ ‑NA‑ ‑NA‑ ‑NA‑
5VSB Volt 4.72 5.00 5.28
Voltage Sensor2 ‑NA‑ ‑NA‑ ‑NA‑ ‑NA‑
© 1999–2023 Cloud Soware Group, Inc. All rights reserved. 195
