PRACTICAL INFORMATION
212
Fuse N° Rating Functions
F19 30 A Windscreen wipers slow / fast speed.
F20 15 A Front and rear screenwash pump.
F21 20 A Headlamp wash pump.
F22 15 A Horn.
F23 15 A Right-hand main beam headlamp.
F24 15 A Left-hand main beam headlamp.
F27 5 A Left-hand dipped headlamp.
F28 5 A Right-hand dipped headlamp.
Engine compartment fuses
The fusebox is placed in the engine
compartment near the battery (left-
hand side).
Access to the fuses
Unclip the cover.
Change the fuse (see correspond-
ing paragraph).
When you have fi nished, close the
cover carefully to ensure sealing of
the fusebox.
Fuse table
