MONITORING
29
TWO-TONE INSTRUMENT PANEL WITH AUDIO SYSTEM
Dials and screens
A. Lighting dimmer (available in night
mode).
B. Reminder of the servicing information
Reset the service indicator or the
trip mileage recorder.
7. Service indicator
(miles or km) then,
total mileage recorder.
These two functions are displayed
successively on switching on the
ignition.
Lighting dimmer setting (when mak-
ing an adjustment).
8. Trip mileage recorder (miles or km).
9. Fuel gauge and associated low fuel
level warning lamp ( a or b accord-
ing to version).
10. Range (miles or km).
Control buttons
1. Rev counter (x 1 000 rpm or tr/min).
2. Gear shift indicator or gear selector
lever position and gear for an elec-
tronic or automatic gearbox.
3.
Analogue speedometer (mph or km/h).
4. Cruise control or speed limiter
setting.
5. Digital speedometer (mph or km/h).
6. Engine oil level indicator.
