TA B L E O F F U S E S
Fusebox C
Ref
.
Rating
F
unction
F1
15A
Rear screen wipe (Tourer)
F2
30A
Locking and deadlocking relay
F3
5A
Airbags
F4
10A
Automatic gearbox - Additional heater unit (Diesel) - Electrochrome rear view mirrors
F5
30A
Front window - Sun roof - Passenger door lighting - Passenger rear view mirror
adjustment
F6
30A
Rear window
F7
5A
Vanity mirror lighting – Glove box lighting – Interior lamps - Torch (Tourer)
F8
20A
Radio - CD changer - Controls at the steering wheel – Display – Tyre defl ation
detection - Electric boot ECU
F9
30A
Cigar-lighter - Front 12V socket
F10
15A
Alarm - Controls on the steering wheel, signalling and screen wipe controls
F11
15A
Low current anti-theft switch
F12
15A
Driver’s electric seat - Instrument panel - Seat belt not fastened warning lamps - Air
conditioning controls
F13
5A
Engine relay unit - Hydraulic suspension pump cut-off relay - Airbag ECU supply
F14
15A
Rain and brightness sensor - Parking assistance - Passenger’s electric seat - Trailer
relay unit - HIFI amplifi er ECU - Hands-free kit - Lane Departure Warning System
F15
30A
Locking and deadlocking relay
F17
40A
Heated rear screen - Exterior heated rear view mirrors
FSH
SHUNT
CUSTOMER PARK SHUNT
