CITROEN C5 2008 - Rear Lamp Unit; Rear Lamp on Boot

166
VI
B
C
A
E
D
F
H
G
C H A N G I N G B U L B S
R E A R L A M P S ( S A L O O N )
Rear lamp unit
Identify the failed bulb.
Bulbs:
A Stop-lamps and sidelamps:
P 21 W / 5 W
B Sidelamp:
R 5 W
C Reversing lamp:
H 21 W
D Foglamp:
H 21 W
E Direction indicator:
P 21 W
Rear lamp on boot
1
Open the boot.
2
Using a fl at screwdriver, remove
the 3 clips which fi x the trim in
the lamp area.
3
Partially remove the trim
F
.
4
Disconnect the connector
G
.
5
Detach the bulb holder
H
.
6
Replace the bulb.
7
Replace the bulb holder
H
.
8
Connect the connector
G
.
9
Replace and fi x the trim
F
with
its clips.
In some climatic conditions,
mist may appear on the
headlamp / indicator lenses.
This is normal and will
disappear (e.g. after the
lamps have been on for a
few minutes). If not, contact
a CITROËN dealer.
