Tailgate-mounted lamps
Rear lamps (Tourer)
Identify the failed bulb.
1. Brake lamps and sidelamps: P21W/5W
2. Sidelamps: R5W
3. Reversing lamps: H21W
4. Foglamps: H21W
5. Direction indicators: PY21W
F Refit the bulb holder H ensuring that it is
correctly clipped in place.
F Position the lamp in its housing.
F Tighten the fixing nut G.
F Refit the connector F.
F Position and clip in place the plastic
cover E.
F Open the boot.
F Using a flat screwdriver, remove the plastic
cover E.
F Disconnect the connector F.
F Unscrew the fixing nut G.
F Disengage the lamp from its housing.
F Unclip the bulb holder H.
F Replace the failed bulb.
You can use the wheelbrace to screw or
unscrew the fixing nut G.
