CITROEN DS 19 - Clutch; Replacement

DS 19 OPERATION No. DS 312-1 Replacement of a clutch. Op. DS 312-1 164
TOOLS
REMOVAL
1 Remove the gearbox (see Op. DS 330-1).
2 Disconnect the clutch from the engine flywheel and remove . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 12 mm box spanner
3 Check the condition of the crankshaft spigot bearing. Also check the thrust race, the clutch operation, its shaft
and tighten the fixing screw.
REFITTING.
4 To connect the clutch to the engine flywheel
a) Make sure that the thrust faces on the clutch and flywheel are clean.
b) Connect the clutch to the flywheel. Use the mandrel (mandrel 171Z-T, see Pl. 44, fig. 4) or a clutch shaft in
order to centralise the disc.
During the tightening of the fixing screws, make sure that the mandrel slides normally, indicating that the
disc has been properly centralised. Tighten the screws to 14.5 + 1.9 ft/lbs (2 + 0.250 m.kg) (spring washers
under the heads).
- 0 - 0
Remove the mandrel . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . Mandrel 1712-T
12 mm box spanner
5 Replace the gearbox (see Op. DS 330-1).
6 Adjust the clutch drag (see Op. DS 314-0).
