DS 19 OPERATION No. DS 133-0 : Adjustment of the rear engine mountings (on the car). Op. DS 133-0 90
TOOLS
ADJUSTMENT (see Pl. 24).
IMPORTANT NOTE – This operation should not be carried out on cars produced after July 1959.
1 Raise the car on a lift or put the front of the car on stands (jacking bracket 2505-T, see Pl. 168) . . . . . . . . . . . . . . . Jacking bracket 2505-T
2 To adjust the left-hand mounting :
Hold the rubber block adjusting nut (5) with the spanner 1700-T
Loosen the locknut (12) with the spanner 1699-T. Tighten or loosen the adjusting nut until the fibre and rubber
washer (9) turns freely without play (spanner 1700-T).
Tighten the locknut (12) (spanner 1699-T) . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . Spanner 1700-T
Spanner 1699-T
3 To adjust the right-hand mounting :
Proceed in the same manner but hold the adjusting nut (5) with the spanner 1699-T and loosen the locknut (12)
with the spanner 1982-T
Check that the nuts fixing the mounting to the body are tight . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . Spanner 1699-T
Spanner 1982-T
12 mm ring spanner
4 Lower the car to the ground.
5 Check that the nut (1) locking the arm (2) is tight (see fig 2) . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 23 mm box spanner
