SECTION 3: SITE REQUIREMENTS & SPECIFICATIONS
Actual Size (ASTRA TEE):
Width: 12.0 inches (30.5 cm)
Depth: 14.0 inches (35.6 cm)
Height: 65.0 inches (165 cm)
Weight: 73 lbs. (33.1 kg)
Minimum Clearances Required:
Front: 12.0 inches (30.5 cm)
Left: 12.0 inches (30.5 cm)
Right: 12.0 inches (30.5 cm)
Top: 4.0 inches (10.2 cm)
Electrical Requirements:
l Service: 115 VAC (±10%) 60Hz, 15A Hospital Grade GFCI receptacle within 8 ft. (2.4 m) is required
l Fuse: 2.0 Amp Slo Blo, 250V, 5 mm X 20 mm
l Category II installation
l Device Rating: 115 VAC (± 10%) 60Hz, 2.0A
Water Supply Requirements:
l A permanent cold-water supply connection within 8 ft. (2.4 m) is required.
l Incoming water pressure: 30 - 85 psi (207 - 586 kPa)
l Recommended minimum flow rate: 1 gpm (3.8 lpm) at 30 psi (207 kPa)
l Temperature: Cold water supply 50 - 80°F (10 - 27°C)
Drain Requirements:
l A drain connection is required using supplied tubing; the device may drain directly into an existing sink,
dishwasher drain tailpiece, or connected permanently to existing plumbing drain.
l The responsible body must provide means to meet back-siphonage protection in accordance to IEC 61770 and
ensure compliance with national and local regulations.
Environmental Requirements:
l Indoor use only
l Altitude up to 6560 ft. (2000 m)
l Operating Temperature: 65 - 80°F (18 - 27°C)
l Pollution degree 2 environment
l Room Humidity 20 - 80% RH non-condensing
l When disposing of this equipment and accessories, follow all applicable national, state and local regulations and
guidelines.
l Ventilation should meet local / hospital standards for area handling High-Level Disinfectants.
Long Term Storage Recommendations:
l Indoor environment (protected from outdoor elements, i.e. rain)
l Temperature exposure greater than 32°F (0°C) to less than 120°F (48.9°C)
l Humidity exposure should not be greater than 80%
M0067_G 3
ASTRA TEE® Installation Manual
