SECTION 4: PARTS REQUIRED
Once the ASTRATEE device is received, the device should be unboxed at the installation site, the contents
confirmed and installation completed prior to in-service.
CAUTION:
The ASTRA TEE device must be tested to your hospital's electrical leakage test
requirements prior to use.
Parts supplied by CIVCO Medical Solutions (with ASTRATEE)
ITEM PART # QUANTITY
ASTRA TEE containing: 610-1338 1
Probe Cable Marker A9061-01 1
Water Filter 610-1340 1
Air Filter 610-1341 1
HLD Bottle Cap Assembly (Small) 610-2000 1
HLD Bottle Cap Assembly (Large) 610-2306 1
Power Cord A7061-01 1
Probe Connector Holder A1064-01 2
Probe Connector Holder Pad (back) A9064-01 2
Probe Connector Holder Pad (base) A9065-01 2
EZ Anchor Kit A6164-01 6
Wall Bracket A1053-01 1
Water Supply and Drain Tubing Assembly A0304-01 1
Operator's Manual M0068 1
Installation Manual (this document) M0067 1
ASTRA TEE Quick Start Guide 50229 1
USB Memory Stick A9058-01 1
Probe ID QR Code Label A9017-01 20
User ID QR Code Label A9018-01 20
ASTRA Troubleshooting Guide W0013 1
Glute Out Bottle (2 oz) 610-1045 1
*Ensure all parts are available prior to attempting installation.
If there are any damaged or missing parts, please call Customer Service at CIVCO Medical Solutions (800) 445-6741.
