eTRAX™ Needle System English
ASSEMBLING NEEDLE SYSTEM
1. Using proper sterile technique, insert needle sensor through opening in cover, taking care to minimize bending of
needle sensor.
2. Extend cover over needle handle.
3. Inspect cover to ensure there are no holes or tears.
WARNING
n Prior to use ensure sheath is securely attached to stylet hub, do not puncture without sheath in place.
4. Using proper sterile technique, insert needle sensor into needle, taking care to minimize bending of needle
sensor.
5. Lock needle onto needle handle, taking care to avoid puncturing cover.
STYLET REMOVAL
1. Once target is reached, rotate stylet hub out of sheath hub by turning counter-clockwise.
