CKD AX1000T Series User Manual

35
TS·TH type driver
Dimensions
TS type driver

TH type driver

G2
G1
T
MON.
SERIES
C
N
2
CN4
+ S2
+ S1
C
N
1
ABSODEX
DRIVER
C
N
3
- S2
CN5
T
B
2
BK +
BK -
- S1
T
B
1
CHARGE
POWER
L1
L3
L2
L2C
50/60Hz
-115V
AC100
L1C
U
V
W
CKD Corporation
MODEL: AX9000TH
MADE IN JAPAN
ABSODEX
ＳＥＲＩＡＬ：+25A1+25A1+25A1+25A1+25A1+25A1+25A1
5
5
95
65±0.5
(Mounting pitch)
(5)
210±0.5 (mounting pitch)
220
6
(100)
160
220
95
Installation hole machining drawing (Note 1)
3-M4 (thread hole)
Driver appearance
Regenerative resistance
75
65±0.5
(Mounting pitch)
5
5(5) 210±0.5 (mounting pitch)
220
Installation hole machining drawing (Note 1)
75
(100)160
220
6
3-M4 (thread hole)
Driver appearance
Note : The mounting pitch differs from conventional models (AX9000GS/AX9000GH)
