CKD AX1000T Series User Manual

Intro8
Torque (N•m)
Index
accuracy
(sec.)
Repeatability
(sec.)
Features Applications Page
210 300 500 1000
AX1210T
±15 ±5
High precision
model with
indexing
accuracy and low
displacement
High speed rotation
(AX1022TS:
240rpm,
AX1045TS:240rpm,
AX1075TS:140rpm,
AX1150TS:120rpm,
AX1210TS:120rpm)


Precision
measurment
Turntable
Inspection
machine
Assembly
machine




1
to
6
±30
±5
High speed
rotation (300rpm)
Small diameter
and low profile
Large diameter of
the hollow hole
(Φ30)



P&P
Turntable
Assembly
machine



7
to
10
AX4300T AX4500T AX410WT
±30
±5
High speed
rotation
(AX4009TS:
240rpm,
AX4022TS:240rpm,
AX4045TS:240rpm,
AX4075TS:140rpm)
Capable of
handling load of
large moment of
inertia
Hollow diameter
is wide large size
option.



Turntable
Inspection
machine
Assembly
machine
P&P




11
to
28
One driver can operate actuators of any size
that are compatible.
The controller function enables the actuator's
rotation angle, movement time and timer, etc.,
to be set as desired with an NC program.
Data is exchanged with an external PLC using
M code output, etc.
TS type;29 to 34
TH type; 29 to 34
CableAX1000T AX2000T AX4000T AX0170H
AX9000TS AX9000TH
Applications Page: 41
Safety precautions : Intro 9
Related parts model no. table Page: 39
Selection guide Page: 43
