CKD FLUEREX PF Series User Manual

PFU Series
How to order
XA14W152000F
PFU
Option
*1
Output
*2
Port size
How to order
Model No.
PFU500F PFU1000F PFU2000F
Code Content
A
Flow rate range
500F 25 to 500 L/min(normal)
●
1000F 50 to 1000 L/min(normal)
●
2000F 100 to 2000 L/min(normal)
●
B
Port size
10 Rc3/8
● ●
15 Rc1/2
●
C
Connection module
3W W3000-10
● ●
4W W4000-15
●
D
Output
Blank Analog output 0 to 5 VDC (standard)
● ● ●
A1 Analog output 4 to 20 mADC
● ● ●
A2 Analog output 1 to 5 VDC
● ● ●
A3 Analog output 0 to 10 VDC
● ● ●
A6 Integrated pulse output
● ● ●
E
Option
Blank No option
X
IN/OUT ow direction reversed (right to left)
● ● ●
N Non-relief
● ● ●
Internal structure and parts list
Refer to page 1374.
A
B
C
D
E
[Example of model No.]
PFU2000F-15-4W-A1X
Model : PFU2000F modular connection
●
A
Flow rate range : 100 to 2000 L/min (normal)
●
B
Port size : Rc1/2
●
C
Connection module : W4000-15
●
D
Output : Analog output 4 to 20 mADC
●
E
Option :IN/OUT ow direction reversed (right to left)
* For combinations not listed in the table, contact your CKD branch or dealer.
*1: For combinations with CKD F.R.L. unit module of the
lter/regulator W*000 Series. For the combinations
with other F.R.L. unit, contact your CKD branch or
dealer.
*2
Code Std.
(Option)
A1 A2 A3 A6
Analog output
Blank (0 to 5V)
● ●
A1 (4 to 20 mA)
●
A2 (1 to 5 V)
●
A3 (0 to 10 V)
●
A6 (Pulse output)
●
Switch output
● ● ●
Precautions for model No. selection
Connection module
*1
Flow rate range
F.R.L
F (Filtr)
R (Reg)
L (Lub)
PresSW
Shutoff
SlowStart
FlmResistFR
Oil-ProhR
MedPresFR
No Cu/
PTFE FRL
Outdrs FR
F.R.L
(Related)
CompFRL
LgFRL
PrecsR
VacF/R
Clean FR
ElecPneuR
AirBoost
SpdContr
Silncr
CheckV/
other
Jnt/tube
AirUnt
PrecsCompn
Mech/
ElecPresSw
ContactSW
AirSens
PresSW
Cool
AirFloSens/
Contr
WaterRtSens
TotAirSys
(Total Air)
TotAirSys
(Gamma)
RefrDry
DesicDry
HiPolymDry
MainFiltr
Dischrg
etc
Ending
1381
Discontinue
