CKD FLUEREX PF Series User Manual

PFU500F to PFU2000F Series
Dimensions
●
PFU500F to PFU2000F
No. Part name Remarks
1 Filter/regulator W3000-10/W4000-15
2 T type bracket set B310/B410
3 Flow rate meter
PFU500F/PFU1000F/PFU2000F
Model No. A B C D E F G H
PFU500F/PFU1000F 189 113.5 104 148 63 45 34.5 Rc3/8
PFU2000F 206 123.5 110 171 80 55 42.5 Rc1/2
Orientation of the display
can be changed
22
A
7
7
Drain outlet
Cable 3 m (attached part)
φ7
φ6
D
E
C
PRESS
TURN
2-H
F
5570
4560
G
68.5
B
1
2
3
F.R.L
F (Filtr)
R (Reg)
L (Lub)
PresSW
Shutoff
SlowStart
FlmResistFR
Oil-ProhR
MedPresFR
No Cu/
PTFE FRL
Outdrs FR
F.R.L
(Related)
CompFRL
LgFRL
PrecsR
VacF/R
Clean FR
ElecPneuR
AirBoost
SpdContr
Silncr
CheckV/
other
Jnt/tube
AirUnt
PrecsCompn
Mech/
ElecPresSw
ContactSW
AirSens
PresSW
Cool
AirFloSens/
Contr
WaterRtSens
TotAirSys
(Total Air)
TotAirSys
(Gamma)
RefrDry
DesicDry
HiPolymDry
MainFiltr
Dischrg
etc
Ending
1382
Discontinue
