CKD PPX Series User Manual

PPX Series
Dimensions with options
Dimensions with options
Front protective cover (PPX-KCB) installation drawing
Cable with connector (PPX-C*)
Model no. Cable length Weight g
PPX-C1 1m Approx. 20g
PPX-C2 2m Approx. 40g
PPX-C3 3m Approx. 60g
PPX-C5 5m Approx. 100g
Connector set (PPX-CN)
Housing: JST MFG CO. LTD. PAP-04V-S
Contact: JST MFG CO. LTD. SPHD-001T-P0.5
Weight: 3g
0V Blue
Standard type: comparison output 2
High function type: analog voltage output or external input
White
Comparison output 1 Black
+V Brown
Terminal name
Insulant color Terminal number
View A
(JST MFG CO. LTD.)
Housing
PAP-04V-S
Contact (crimping)
SPHD-001T-P0.5
33.4
33.4
24
50
Connector
Front protective cover
34.5
34.5
39.3
20
11 18.3
Panel thickness 0.5 to 6
(35)
A
L
(50)
(8)
3.7 cable
(8)
Conductor cross-section
areas 0.2mm
2
Insulator outer diameter
of
1.1mm
4
3
2
1
6

CKD PPX Series Specifications

General

Proof pressure	1.5 MPa
Pressure port	Rc 1/8
Port Size	Rc1/8
Piston Material	Stainless steel
Rod Material	Stainless steel
Seal Material	NBR
Fluid	Air
Withstand voltage	AC 1500 V, 1 min
