298 332.0 - RHB ROLLANT 250 / 250 RC
1.1.3
General
Key to symbols
This CLAAS REPAIR MANUAL uses some symbols as
defined in the “DIN 30600 Symbol summary” by the
German Standardisation Institute (DIN).
The meaning of these symbols will be easily
recognised and remembered by the user. These
symbols are to help to quickly recognise recurring
service procedures and they also help to communicate
information shown on the illustrations.
Dismantle,
remove
Grease
Prevent damage to
materials
Disassemble Oil Special tools
Assemble Adjust/set
Drain,
outlet
Install,
mount on
Check visually
Fill,
filler opening
Mark
Unlock, release,
secure
Overflow
Balance
Lock by means of
liquids,
glue, seal
Bleed
Possibly reuseable
Underprop,
support
Renew on
each assembly
Observe direction of
installation
